Rugged Substation Automation Computer RSAPC - WELOTEC
Varebeskrivelse
Stand: Som ny - ingen synlige brugsspor
Mærke: Andre mærker
To stk. IEC 61850-3 certified Rugged Substation Automation Computer
(Professionelle industri computere - 100% passivt kølede).
Pris er pr. stk.
Med strømforsyning - uden lagermedie (HDD/SSD etc.)
Beskrivelse og billeder følger.
Se evt. -> https://welotec.com/products/rugged-substation-automation-computer-rsapc
CPU
CPU Intel® Xeon® Processor E3-1505L v6
Generation Kaby Lake, 7. Generation
Available till 2032
Frequency / Frequency max 2.2 GHz / 3.0 GHz
Cores / Threads 4 Cores / 8 Threads
L2 cache 8 MB
Passmark CPU Perfomance ~7800
Memory / RAM
Socket type 2x SO-DIMM 1.2 V
Storage type DDR4 ECC (2133 MHz)
Capacity max. 64 GB
Chipset
Chipset Intel CM238 Chipset
Storage
mSATA Socket 1x Full Size Socket (max. 512 GB)
Internal Drive Bay 2x 2.5 inch SATA HDD/SSD Hot Swappable Bay
SATA Controller Intel CM238 SATA Controller provides standard AHCI and Intel RST RAID modes
Interface for Bays SATA II 3.0 Gb/s
RAID RAID Level 0, 1
Graphics
Graphic chip (GPU) Intel® HD P630 Graphics Controller
Direct X Level Level 12
OpenGL 4.4
Displays DVI-D (max. 1920 x 1200 @ 60 Hz) / DisplayPort 1.2 (max. 4096 x 2304 @ 60 Hz)
Interfaces & Features
USB 5x USB 3.0 (4x rear, 1x front with key lock) + 1x internal USB 3.0 onboard Type A
PCIe Expansion 1x PCIe x16 slot, full length, full height / 3x PCIe x4 slot, full length, full height
Serial Ports 2x RS-232/422/485 (DB9 with isolation)
Ethernet 4x RJ45 10/100/1000 Mbps copper ports, Intel® Ethernet-Controller I210-IT
Real-Time Clock/Calendar 3V 230mA PANASONIC CR2032L-JP-W-1A
BIOS AMI UEFI
Trusted Platform Module Infineon SLB9665XT2.0 TPM2.0
Power supply
Power supply 2x slots for power supply unit modules
Fuse Ratings AC 5 A / 25 V, DC T15 A / 400 V 5 HP
Terminal Connections Current rating: 16 A, 300 V AC / Insulation withstands volt: 2000 V AC min / Insulation resistance: > 2000 M \Omega Ohm 500 V DC / Operation temperature: -40°C to +105°C / Wire strip length: 4 mm to 5 mm / Wire range: 12 to 24 AWG / Screw torque: 0.8 Nm (7 in-lb)
Physical characteristics
Housing colour Pantone® Gray 446
Dimensions (W x H x D) 438 x 129 x 292 mm
Ingress protection ´ IP20
Weight 8500 g
Mounting 19 Inch Rack
Environmental
Operating temperature range -40 - +75 °C
Storage temperature range -40 - +85 °C
Humidity 5 % to 95 % @ 40 °C
Insulation Class Class 1
Approvals
CE (EU) Yes
RoHS Yes
REACH Yes
FCC Yes
UL/cUL Yes
IEC 61850-3 Yes
IEEE 1613 Yes
CB Yes
Azure Certifed Device Yes
Edge managed (Azure) Yes
AWS IoT Greengrass Yes
