Billedgalleri
Technics Videoafspiller CD Forforstærker Technics
Varebeskrivelse
Stand: Brugt - men i god stand
Technics Videoafspiller CD
Forforstærker Technics
SU-V620M2
Technics (brand)
Country
Japan
Manufacturer / Brand
Technics (brand)
Year
2000
Category
Audio Amplifier or -mixer
Radiomuseum.org ID
298658
Schematics
SU-V620M2; Technics brand (ID = 2225006) Ampl/Mixer
Technics brand SU-V620M2 (2)
Photo Catalog Technics
Previous
Next
Technical Specifications
Number of Transistors
Semiconductors present.
Semiconductors
Main principle
Audio-Amplification
Wave bands
- without
Details
Remote Control (with wire or wireless)
Power type and voltage
Alternating Current supply (AC) / 220/240 Volt
Loudspeaker
- This model requires external speaker(s).
Power out
200 W (undistorted)
Material
Metal case
from Radiomuseum.org
Model: SU-V620M2 - Technics brand
Shape
Tablemodel, low profile (big size).
Dimensions (WHD)
430 x 125 x 317 mm / 16.9 x 4.9 x 12.5 inch
Notes
Integrated Stereo Amplifier, Serie MASTER,(capacitors TA-KEH), Power output 2x100 W, (4 ohms), input selection : Cassete 1, Cassette 2/ DCC, Aux, DVD, CD, Tuner, Phono, A-B columns selector, bass/treble/balance control. out headphones, remote control.
Continuous power= 2 channels simultaneously, 2x100 W (4 Ω), 2x80 W (8 Ω) 20Hz-20kHZ--2x70 W (8 Ω)
Harmonic Distortion-20Hz-20kHz--0,1 % (8 Ω)
Frequency Range-- Phono MM :RIAA standard curve--+- 1 dB(30Hz-15kHz), Tuner, Cd, DVD-6 channels, Aux, Tape 1, Tape 2/ DCC--3Hz-60kHz (+0dB ,-3 dB--+0 dB,-3dB (20Hz-20kHz,
Signal Noise Ratio (4 ohms)-Phono MM--76 dB(77dB,IHF '66, CD,Aux, Tuner, Tape 1, Tape 2/DCC--92 dB (95 dB, IHF'66)
In Sensitivity/Impedance : Phono MM2,5 μV/47 kΩ, Cd, Aux, Tuner, Tape 1, tape 2/DCC---150 μV/22 kΩ.
Net weight (2.2 lb = 1 kg)
6.8 kg / 14 lb 15.6 oz (14.978 lb)
Mentioned in
Technics (brand) Catalogs (Catalog Technics 2000, Model Page 10)
Author
Model page created by Manuel Albano Neves. See "Data change" for further contributors.
