Varebeskrivelse
ARX Audibox USB DI, ARX Audibox USB DI,
Beskrivelse fra produktside:
ARX USB DI - a true Plug and Play 24 bit High Resolution digital to analog pro audio interface. It removes the need to use any existing sound card outputs, with their inherent noisy environment and problematic grounding.
The USB DI installs as a fully compatible generic USB audio device, requiring no special driver program installation on Mac OSX, Win XP, Windows 7, 8 and 10
The front panel has a Type B USB input connector and two transformer balanced analog audio XLR Line out connectors for connecting to any standard balanced analog input.
A status LED on the front panel indicates that the USB DI is connected and operating.
The USB DI is housed in a heavy duty all-steel chassis finished in attractive matt textured powdercoat, with hardwearing epoxy screen printing and slip resistant rubber pad. It is ideal for interfacing any USB equipped computer (especially notebook computers) with the balanced inputs of professional sound systems.
USB-DI Specifications:
- Input Connector USB type B port
- Codec 24 bit High Resolution, , 44.1, 48 KHz and 96KHz
- Output Impedance 300 Ohms Transformer Balanced
- Output Level Maximum nominal output level 0dB
Output Noise
- USB - System dependent
- ISO transformer - Enviroment sensitive
- Frequency Response 20 - 20 KHz ± 0.5 dB
- Power Operating current via USB Port 80mA
Output Connectors_
- 2 x Male XLR, wired Pin 2 + Hot, Pin 3 – Cold. Pin 1 Floating / not connected
Construction_
- All-steel powdercoated chassis, fibreglass PCB, epoxy printing, slip-resistant rubber feet
- Optimal storage temperature range 0'C - 40'C
- Operating temperature range 0'C - 50'C
System Requirements:
- Windows PC running Windows XP, Windows 7/8/10, Mac running OS X or later
