PISTOLHOVED HUN 3 PHASE, 16A ELLER 32A, EU STANDARD
Til salg599 kr.
Beskrivelse
Andet biltilbehør, Pistolhoved hun 3 Phase, 16A eller 32A, EU standard
Data
Product
AC Type 2 Female Plug EU standard
Electric Data
Power Supply
1P+N+PE+CC+CP / 3P+N+PE+CC+CP
Rated Voltage
480V
Rated Current
16A/32A
Frequency
50/60Hz
Insulation Resistance
More than 1000MΩ
Terminal Temperature Rise
Less than 50K
Withstand Voltage
2000V
Contact Resistance
0.5mΩ
Mechanical Data
Mechanical Life
More than 10000 times no-load plug in/out
Coupled Insertion Force
45--100N
Withstanding Impact
Dropping from a 1m height and running over by a 2T vehicle
Material
Fire Rating
Thermoplastic, flame retardant grade UL 94 V-0
Cable Material
TPE/TPU
Cable Length
5m or as requested
Terminal
Copper alloy, silver plating
Environment
Work Temperature
-30°C-+50°C
Work Humidity
5%-95%
Work Altitude
Less than 2000m
Ingress Protection
IP54
