DirectOut Andiamo.MC MADI Preamp/Line Out
Til salg
Fiks færdig
25.000 kr.
Fragt fra 59,99 kr. + Tryg betaling 760 kr.
Tryg handel med Fiks færdig
Fiks færdig er DBA's nye betalings- og fragttjeneste. Efter levering har du 24 timer til at kontrollere varen, før pengene udbetales til sælgeren.
Varebeskrivelse
Stand: Brugt - med synlige brugsspor
DirectOut Andiamo.MC
32 MADI Microphone Preamps/32 MADI Line Outputs
Discontinued product (since they launched the DirectOut Prodigy), but an absolutely rock-solid, reliable and fantastic-sounding unit.
Unit condition described as "used with visible signs of wear", due to one of the unit's fans recently became a little noisy. Should be an easy fix though.
-
Trading has no interest.
New as price: 59.995,94 kr.
Price: 25.000. Open to offers.
Selling on behalf of a company/production I work for. Buyer can receive company invoice from purchase upon request.
Pick up in Copenhagen, Denmark, or sent worldwide at buyer's expense.
-
ANDIAMO.MC is a high-end 32-channel mic preamp and AD/DA MADI converter with a full MADI routing matrix that forms part of DirectOut Technologies‘ extensive range of premium quality MADI converters. It allows the conversion of mic level signals into MADI digital format. 32 line outputs in balanced line level analog format offer comfortable monitoring or stage returns.
Sophisticated design and a high level of integration have resulted in a compact, easy-to-handle 2U 19” form factor, ideal for studios, OB vans or other live recording environments where rack space is limited.
The device can be operated locally or remotely via the ANDIAMO Remote software. Supported remote methods are USB, D.O.NET, ‘MIDI over MADI’, ‘Serial over MADI’ and from mixing console.
Protocol Support:
– AVID (PRE™)
– Yamaha (DM2000,DM1000)
– SSL (C10, C100 & C200)
– Lawo (Dallis)
Quick Overview:
The front panel provides status LEDs for real-time monitoring of signal condition for all input and output channels.
Clocking:
Selectable clock sources are word clock, MADI input or the internal clock. The current system clock is provided at the word clock output at any time.
Port Redundancy:
ANDIAMO.MC is equipped with two MADI ports as standard, offering seamless port redundancy. Both MADI outputs always carry identical signals.
Extended Routing:
The Extended Routing feature enables both MADI I/Os to be used independently to:
– create two individual MADI feeds
– double the range of available MADI input channels
– make full use of all conversion channels at higher sample rates
GPO:
Two GPOs may be confi gured individually in order to monitor critical system events or to trigger a recording light.
Safe Operation:
Thanks to two phase-redundant power supplies with separate IEC inlets and AC power switches on the rear panel the device offers the highest reliability.
TECHNICAL DETAILS:
MADI Ports (I/O):
2 x SC-Socket multi/single-mode or
1 x SC-Socket multi/single-mode &
1 x coaxial BNC, 75 Ω
Analog (I/O):
8 x DSUB-25 (balanced)
Input Sensitivity:
-55 dBu to +30 dBu
30 dB PAD (switchable)
+48 V phantom power (switchable)
Output Level:
+24 dBu (digital trim)
A/D Section:
EIN: -128 dB
THD @ -1 dBFS: -113 dB
Frequency Response:
-0,15 dB (10 Hz) / -0,15 dB (20 kHz)
D/A Section:
SNR: -116 dB RMS (20 Hz - 20 kHz) / -119 dB(A)
THD @ -1 dBFS: -109 dB
Frequency Response:
-0,5 dB (10 Hz) / -0,15 dB (20 kHz)
Word clock (I/O):
Coaxial BNC (75 Ω termination switchable)
GPO:
2 x MOSFET switch
USB:
USB 2.0 for remote control and firmware updates
Sample Rates:
44.1, 48, 88.2, 96, 176.4, 192 kHz (+/- 12,5%)
MADI Formats (I/O):
48k Frame, 96k Frame, 56/64 channel, S/MUX
Power Supply:
2 x 84 V to 264 V AC / 47 Hz to 63 Hz / safety class 1
Dimensions:
Width 19’’ (483 mm)
Height 2 RU (89 mm)
Depth 10’’ (254 mm)
Weight:
About 7 kg.
