Yorkville 100KW monitor
Varebeskrivelse
Stand: Brugt - men i god stand
Kraftig amp/monitor med indgange til mic og keys/instrument samt RCA til musik etc.
Gode enheder. God især som keyboard monitor.
Har brug for kontaktspray hist og her, den har lidt knas på volumeknappen. Men alting virker.
Derfor sat lavt i pris!
Yorkville's 100KW "omni-wedge" is designed for the professional musician or performer who needs a portable 100-Watt powered monitor or instrument/vocal amplifier that travels well. Two input channels with a selection of 1/4-inch, XLR or RCA inputs mean the 100KW can connect to virtually any source from PA or recording desk to keyboard instrument, recorded media source, acoustic/electric guitar and/or a microphone. Additionally, effects can be patched-in or alternately the amp and speakers can be slaved as a PA monitor, and the Headphone jack disconnects the full-range 2-way 12-inch/horn-and-driver speaker system for silent practicing.
The 100KW's black carpet finish covers a solid plywood cabinet construction. The curved, perforated all-metal grille protects the speaker components.
Features:
• 100 watt powered wedge monitor
• Two discrete input channels
• 12-inch woofer & 1-inch ABS horn design
• Solid plywood cabinet construction
• Curved all-metal heavy gauge perforated metal grille
Specifications:
• Cont. Power @ min. impedance (Watts): 100
• Minimum Impedance (Ohms): 4
• Burst Power, 2 cycle: 115 Watts
• Woofer: 12 inch, 100 Watts
• Horn & Driver: 1 inch, 30 Watts
• Channel 1 Inputs: XLR Mic/Line, 1/4-inch TRS Inst./Line
• Channel 1 Controls: Volume
• Channel 2 Inputs: 2 x 1/4 inch TRS, L&R RCA
• Channel 2 Controls: Volume
• Channel 2 Switches: Reverb Defeat
• Master EQ: Low & High EQ shelving above & below 1kHz
• Input Sensitivity (mV): ch. 1 XLR=3 Phone= 20, ch. 2 Phone=75 RCA=150, ch. 3 Phone=75
• Line Out: 1/4 inch (Effects Send)
• Line Out Level (Vrms): 1
• Effects Loop: Serial
• Effects Return: 1/4" TRS, isolates the amplifier section and speaker system for "slaving" the 100KW as a PA monitor
• Effects Return Sensitivity (Vrms): 1
• Headphone Jack: 1/4-inch TRS, defeats speaker system
• LED Indicators: Power
• Limiter: Undefeatable,limits power amp clipping
• Cabinet Construction: multi-ply spruce
• Dimensions (DWH, inches): 19 x 17 x 19
• Dimensions (DWH, cm): 48 x 43 x 48
• Weight (lbs / kg): 39/17.7
