Billedgalleri
DAC, Firestone, Spitfire mk 2
Varebeskrivelse
Stand: Som ny - ingen synlige brugsspor
Mærke: Andre mærker
DAC, Firestone, Spitfire mk 2, Perfekt, Restlager fra webshop
Ny og ubrugt.
Amplifier Structure: Low pass filter with 2Vrms output
Power Structure: Virtual-Ground power supply
S/PDIF D/A Chip: Burr Brown PCM1793: (24 Bit - 96 kHz Max)
Audio Data Receiver: Burr Brown DIR9001 – 96 KHz
USB Chip: Burr Brown PCM2704 (16 Bit - 48 kHz Max)
Opamp: NS - LM4562MA (Fitted in an 8 Pin DIP socket to allow easy Opamp rolling)
Output Voltage: 2 Vrms
Output Impedance: 100 ohms
Audio Performance: S/PDIF (Optical and Coax)
Frequency Response: 10Hz~25Khz ,-1dB at 600 ohms loading
Noise Level: -112.1 dB (1 KHz, A-Weighted)
Dynamic Range: -112.1 dB (1 KHz, A-Weighted)
Stereo Crosstalk: -109.8 dB
THD: 0.004%
Audio Performance - USB
Frequency Response: 10Hz~25Khz ,-1dB at 600 ohms loading
Noise Level: -96.1 dB (1 KHz, A-Weighted
Dynamic Range: -96.1 dB (1 KHz, A-Weighted)
Stereo Crosstalk: -109.8 dB
THD: 0.004%
Inputs: 1 X USB, 1 X Toslink optical, 1 X digital coax (USB priority)
Output: 1 X Gold Plated RCA
Size Size:: 11cm/4.3in(L) x 8cm/3.2in(W) x 5cm/2.0in(H)
Weight: 300g / 10.6oz
Additional Features:
DC amplifier uses no coupling capacitors
Output short / over current protect
Bemærk: Knappen til at vise den fulde beskrivelse har kun en visuel effekt.
